Detalles técnicos

• Builder: AES Yachts
• Year: 2027
• Exterior Design: AES Yacht
• Interior Design: Hot Lab
• Naval Architecture & Engineering: AES Yacht/Endaze Engineering
• Length Overall: 26.13 m/85 ft 8 in
• Length at Waterline: 22.74 m/74 ft 7 in
• Beam: 7.86 m/25 ft 9 in
• Max Beam: 8.00 m/26 ft 2 in
• Depth: 3.75 m/12 ft 3 in
• Gross Tonnage: 235 gt
• Material del casco: acero
• Material de la superestructura: Aluminio
• Class: RINA C ✠ HULL ● MACH Y, Unrestricted and CE Cat A
• Bandera: Malta
• Engines: (2) Cummins QSM 11 455 hp
• Max Speed: 11 knots
• Cruising Speed: 8 knots
• Range at Cruising Speed: 6,000 nm
• Generators: (2) Kohler 35 kW @1,500 rpm 50 Hz, 400V
• Fuel Tank Capacity: 35,500 liters/9,379 gallons
• Fresh Water Tank Capacity: 3,558 liters/940 gallons
• Sewage Tank Capacity: 3,953 liters/1,044 gallons
• Staterooms: 4; sleeps 8 guests
• Crew Cabins: 2; sleeps 4 crew

Propulsion & Auxiliary Machinery

• ZF Gearbox
• F51 Duplex stainless steel shaft
• (4) Control stations
• Aluminum bronze propeller
• Bow Thruster: (1) Sleipner SH550, hydraulic
• Stern Thruster: (1) Sleipner SH550, hydraulic
• Data hydraulic steering system
• Stabilizers: Sleipner, zero speed, vector fin kit 1.95 sqm
• Danfoss PTO pumps
• Water Makers: 460 liters(121 gallons)/hour total, duplex, Idromar
• Idromar fresh water systems
• Air Conditioning: Mediterranean Climate – Webasto
• Engine Room Inlet & Outlet Fans: (2) Gianneschi
• Fuel Filtration: (1) Alfa Laval
• Sewage Treatment System: Hamann, HL compact 3,000 liters (792 gallons)/day
• Sistema sanitario Tecma
• Gianneschi pumps
• (1) Alfa Laval fuel separator and filters
• (1) Atlas Copco compressor
• bocina de aire Kahlenberg

Sistemas eléctricos

• Electrical Supplies: 230/400V – 50hz
• Batteries Starter & Service: Mastervolt or Victron
• Service Generator: (2) Kohler 35 kW with Sound Encloser
• Shore Power: (1) Glendenning Cable Master
• AV & IT Automation System: KNX, ABB

Deck Equipment & Coating

• (2) Data hydraulic anchor winches (windlasses)
• (2) Data hydraulic mooring winches (capstans)
• (2) Data hydraulic anchor & anchor chain
• Tender Crane: (1) Opacmare – Loading capacity 1,000 kg
• Transformer: (1) Opacmare 5 steps – Lifting capacity 420 kg
• Passarelle: (1) Opacmare – Length 5.040 mm
• Electrical Sliding Doors: (2) Besenzoni or Makro Yachts
• (8) Underwater lights or Oceanled
• Awl Grip top coat (topsides & superstucture)

Sistemas de seguridad

• Sliding Watertight Doors: Winel or equal
• Fire Fighting: Fire Pro FP 1200
• Fire Detection & Alarm: Tyco T2000 or Consilium
• Security (CCTV): Samsung

Navigation & Electronic Equipment

• Furuno navigation equipment
• Luces de navegación
• (1) Intellian TV antennas
• Network IT system
• 4G/WiFi system
