DESCRIPTION DÉTAILLÉE
CARACTÉRISTIQUES
NAVAL ARCHITECTURE: ALFA MARINE DESIGN
EXTERIOR STYLING: RED YACHT DESIGN
INTERIOR DESIGN: RED YACHT DESIGN
INTERIORS MANUFACTURERS: MSM
FRESHWATER TANKS: 8,656 M3 (2X SAILOR S 3/40
PLANT WATERMAKER:8.4 TONNES / DAYS WITH SILVER ION STERILIZER TY 168 )
SANITARY TANKS: 7,586 M3
CLASSIFICATION: RINA; C .HULL . MACH YCH, SHORT RANGE NAV.
CONSTRUCTION: GRADE A STEEL HULL, MARINE ALUMINIUM SUPERSTRUCTURE
STABILIZER: ABT TRAC 440 (ZERO SPEED)
PAINT SYSTEM: AWLGRIP-JOTUN/ JOTUN
GUEST ACCOMMODATION: 1X MASTER STATE ROOM, 4X GUEST CABİNS
CREW ACCOMMODATION: CAPTAİN + 8
MAIN ENGINES: CATERPILLAR 2 x 1450 BHP @ 2300 RPM With SCR
GEARBOX ZF: 3310 RATIO 3.5:1
SHAFT SYSTEM: RADICE WITH VULKAN VULKARDAN F THRUST BEARING PROPFLEX
TENDER BOAT: CASTOLDI JET TENDER 16
AUXILIARY MACHINERY & ELECTRICAL SYSTEMS
PRINCIPAUX GÉNÉRATEURS :
2 x CATERPILLAR C4.4 MODEL 86 ekW @ 1500 RPM
1 fois CATERPILLAR C4.4 MODEL 51 ekW @ 1500 RPM
ÉQUIPEMENTS AUXILIAIRES
STEERING SYSTEM: HYDRAULIC STEERING SYSTEM
STERN THRUSTER: ABT TRAC 440 HYDRAULIC STABILIZER
RUDDER ANGLE INDICATORS: MECHANICAL RUDDER ANGLE INDICATOR
BOW THRUSTER: ABT TRAC BOW THRUSTER 24″
SEWAGE TREATMENT: HAMANN SEWAGE TREATMENT
AIR CONDITIONING SYSTEM: HEINEN HOPMANN
VENTILATION: MECHANICAL VENTILATION SYSTEM
WATERMAKERS: SAILOR S 3/40 WATERMAKER PLANT
ANCHOR WINDLASS: WINDLASS
PASSERELLE: OPACMARE PASSERELLA
SYSTÈMES DE DIVERTISSEMENT
TVs:
• 50-inch: 6 PCS
• 55-inch: 4 PCS
• 43-inch: 3 PCS
GALÈRE
MIELE
• APCL 001 Interconnection Bar Inox (Quantity: 2)
• KM 7897 FL NC Induction Cooker (Quantity: 1)
• M 2230 SC Built-in Microwave (Quantity: 1)
• M 7240 Built-in Microwave Oven (Quantity: 1)
• CM 6360 Solo Coffee Machine (Quantity: 3)
LIEBHERR:
• FKUV 1663 Beverage Cabinet (Quantity: 2)
• UWTGB 1682 Built-in Under-counter Wine Dish (Quantity: 1)
ELECTROLUX:
• 691352 1 Door Prostore Deep Freezer 470 Lt (Quantity: 2)
• 691345 (PS04R1FLHC) Refrigerator 1 Door, Prostore, 470 Lt (Quantity: 2)
• 691346 1 Prostore Refrigerator with Glass Door 470 Lt (Quantity: 1)
• 730272 Cube Ice Machine (Quantity: 2)
• EEA 12100L Fully Built-in 45 cm Dishwasher (Quantity: 2)
RATIONAL:
• iCombi Pro XS 3 NAC400 V 50-60 Hz Marine Model (Quantity: 1 Oven)
ULTRAVENT:
• Plus XS with XS 6-2/3 Concealed Installation Kit (Quantity: 1 Kitchen ventilation system)
ZESIS
• M33 Single lever kitchen mixer 150, pull-out spray, 2jet, sBox lite (Quantity: 2)
BLANCHISSERIE
MIELE
• PWM 908 DP SST Laundry Washing-Spinning Machine ProfiTronic M (Quantity: 2)
• PDR 908 HP SST Washer Dryer ProfiTronic (Quantity: 2)
• HM 16-80 Industrial Type Roller Cylinder Iron Steam (Quantity: 1)
