Information & Features

Caterpillar C18 (Engine 1) Type: Inboard Fuel Type: Diesel
Hours: 545

Power: 1150  hp


Caterpillar C18 (Engine 2) Type: Inboard Fuel Type: Diesel
Hours: 545


Power: 1150  hp


Dimensions
LOA:                       76 ft 9 in LWL:                       64 ft 5 in Beam:                      19 ft 6 in


Min Draft: 4 ft 10 in

Weights
Displacement: 84,000 lb

Speed
Cruising Speed: 20 kn
Max Speed: 26 kn

Tanks
Fuel: 3,000  gal Fresh Water: 500 gal Holding: 150 gal

Accommodations
Heads: 5



General Arrangement



Magic is a Raised Pilothouse Motor-yacht with an upper and lower helm station. She can be easily piloted and docked from either location.  She features large salon on the main deck and up a few steps in the galley you find a large U-shaped galley and nice seating area. The main accommodation area below has 3 staterooms, all with their own heads and separate showers. The Master Stateroom is very large and is the full beam of the boat.   The Master Head has 2 separate (his and hers) sinks and toilets, and they share a large shower in the middle.

The Fly-bridge has 2 comfortable helm chairs and a top of the line set of Garmin electronics.  Aft of these seats there is a large built in seating area and table for guests.  There is ample storage, a grill, and drink fridge up here too.  Aft of the seating area you find a davit and dingy.

Outside in the cockpit of the boat you find Port and Starboard seating areas with their own tables.  There is a full height stairway on the port side that leads to the crew cabin and engine room.   This space is ample for a crew of 2 and is finished nicely so family could use this space as well.

The hull is pained in Awlcraft Medium Silver with two coats of Awlcraft 2000 clear on top.  This yacht finish is what you would expect on a high-end sports car, but rarely can be found on a yacht of this size.   The Superstructure is a pleasant Oyster White that is much more pleasing to the eye in the tropical sun than a bright white.  The lower decks are perfectly laid natural teak, undoubtedly the best nonslip surface under foot on a choppy day.   The upper decks are non-skid to keep the weight down and for ease of maintenance.

The main cabins on the lower deck feature 3 Staterooms and 3 heads all with separate showers. The Cabin-way has a nice stacked washer and dryer behind solid Cherry louvered doors and there  is a great  folding area off to the side.

Magic is a perfect family yacht that is safe and comfortable for all those that cruise on her.



Equipment on Deck



Twin Lewmar chain/rope windlasses



Stainless Ultra 60KG anchor with 300′ of chain



Stainless 70KG Bruce secondary anchor with 150’ ¾” nylon with 30’ chain spliced on port.



Fuel fill Port and Starboard with overflow bin.



Fuel shutoff from side deck



FireBoy Manual deploy from side deck



Water fill up high on pilothouse



4 boarding doors aft



2 50A Cablemasters aft and one 50A Cablemaster forward



Boarding stairs with integrated handrail



Oval Stainless bow rails and grab rails



Salt and Fresh Water washdown Bow and Stern



Underwater lights



800 KG Davit with rotation, telescoping, wireless remote



Exterior Speakers in cockpit and on FlyBridge



Salon

The Salon is accessed from the aft through  a set of sturdy  double doors.  Upon entry, you will notice the classic teak and  holly flooring. The interior cabinetry is beautiful satin finished Cherry.  To starboard there  is a large settee with ample storage underneath with an attached desk  just forward of this seating area. To port a comfortable chair and settee that matches the settee across from it separated by a beautiful Cherry  table. The aft starboard corner  of the room houses a wine cooler under  counter with glass storage above. The aft port corner  has a bar-style setup that includes a refrigerator, sink, bottle storage under  counter, and  additional glass storage above the counter. . As you look to the very forward section of the room, you can  see over the galley countertops to the forward Pilothouse windows giving the open  feeling of a much  larger yacht.
She  has all the creature comforts you would expect in a yacht of this class, large flat screen TV, Surround Sound
Stereo, Bar area with beautiful glass storage lockers.

Uline wine cooler

Subzero beverage center

Bose Stereo

Built in sink

Teak  blinds

Teak  and  Holly floors



Galley / Dining

Forward  of the salon and  up three  steps brings you to the galley and  dining area. The galley is well equipped and outfitted even  for the most  demanding of chefs. Countertops are  Light colored Quartize (Calcite Azul) and  offer plenty of surface area for the chef on board.   In this space with ample storage all the way around. Just  forward of the galley to port is a large seating area. The 360 degree views from this dining area allow for a relaxed environment to soak  in the beauty of your surroundings.
The galley is U shaped and  provides you access to the sink, cooktop,  oven  and  refrigerator and  freezer drawers from your natural standing position in the center of the space. The 2 SubZero units provide  you 3 refrigerator drawers and  one  Freezer Drawer.   Right next to the sink you will find a Fisher Paykel Dishwasher and  on the starboard side  is the Dacor  5 burner  Induction cooktop  and  just below is the full size  Dacor  Oven.   Aft above in the over head cabinets is a June convection toaster oven.  There  is lots of cabinet space throughout the galley and  a generous hatch  to drop trash  in one  of the 2 trash  bins.

2x Subzero refrigerator/freezer units (3 refrigerator, 1 Freezer drawer)

Dacor  Cooktop  (Induction)

Dacor  Oven

Fisher Paykel Dishwasher

Large  Franke Sink with Disposal

June Convection oven

Teak  blinds

Quartize countertops

Built in Trash  drawer  for 2 cans (slide out)

Lower Helm

The Lower Helm is a great  spot  to operate the vessel from on less than  perfect days.  You are  far enough forward to see the crab  pots and  just a few steps from a cold drink in the galley.  It is great  to stand watch  from this position and  have  lunch with the family in quiet air-conditioned comfort.  The ships main systems are  easily monitored from this station.
There  are  2 large Garmin Displays and  the engine control panels are  right in front of you as well as the other yachts systems.  Everything you need to operate the vessel day or night is right at your fingertips.
The overhead panel has a diagram of the ships warning systems and  an LED light indicates when  Bilge Pumps are running, High water  Alarm, High Exhaust Temperature, and  even  lets you know if the Transom door is properly closed.  Also overhead, you will find a tank monitoring system that lets you know the level of all tanks  on board  and there  is a Voltage Monitor display that will show you the voltage of all battery  banks.  This is truly the command center of the yacht.

Stidd Helmchair

2 large Garmin Displays

Engine Displays and  key switches

Autopilot Control

Spotlight Control

FLIR Night Vision Control

Multifuncion displays for Water  depth, Wind Speed, Wind Direction, Boat Speed

Backup  Steering Joystick

Stabilizer Control

Wiper Control with Wash

Air Horn Compass VHF Radio

Deck/Cockpit

You can  board  “MAGIC” from the swim platform or from one  of the boarding gates on either side  amidship. From the swim platform looking forward you will notice the unique divided transom with the single row of steps going up the middle of the stern up onto the cockpit. Once  on the cockpit, you will find two separate seating areas to the starboard and  port aft corners of this space, each with a varnished teak  table securely fixed to the deck.  On the forward starboard corner of the cockpit there  is a pop out docking  station equipped with throttle controls and bow and  stern  thrusters. On the port side,  are  steps leading up to the upper  aft deck  with a door under these steps that provides access  to the crew quarters and engine room.

Engine/Mechanical

• Twin Caterpillar C18 1150  HP engines (545 hours)
• Two 21.5kW Onan  generators in custom sound shields (440 & 415 hours)
• Yacht Controller
• Outback inverter and  charger
• Centaur 24V 60AMP Charger
• Centaur 12V 40AMP Charger
• (2) ANG ISO-Boost transformers, 12.5kva  each
• Side Power  Bow Thruster (15HP)
• Side Power  Stern  Thruster (15HP)
• Backlighted electrical Panels
• Carbon Monoxide  detectors in all berthing spaces
• Soft Motor Mounts
• Two Cross-Connected Sea Chest Sea Water  Intakes with cleanouts
• Drypoint Demister air Intake System
• FRP Fuel Tank (3000  gallons) with sump  and  cleanout
• Fuel Manifold and  proprietary Glass Sight Gauge
• Dual Racor  fuel filters with pressure gages for each engine and  generator
• Fire Suppressant System
• Engine Room  Lead/Foam Sound and  Heat  Insulation System
• 4x 220V High Volume Engine Room  Blowers
• Color coded Piping
• Polished Stainless-Steel Engine beds with carbon fiber stringers
• Gel coated bilges
• Oil change system
• LED Engine Room  Lighting
• Common Drainage System from Bow to Stern  collects deck  drain, scupper and  sump  discharges
• Underwater Exhaust
• Underwater lights
• AGM Batteries
• Air-Conditioned Engine Room  and  Crew Quarters
• Morse Electronic controls
• Naiad 252 Model Stabilizers
• Twin Aircon Pumps
• Twin Fresh water  pumps

Flybridge and Boat Deck

The Flybridge on “Magic” provides a 360 degree view giving you great  sight lines while navigating. Fully equipped with an array  of navigational tools including 2 large Garmin Screens, Autopilot, Yacht Controller, VHF radios, and  numerous others, she  is a dream vessel for any captain. There  are  2 Stidd captains’ chairs mounted at the helm with all navigational equipment at your fingertips. Behind the Helm seats is a comfortable L shaped settee and  table.
Aft of the Flybridge, the upper  aft deck  on “Magic” houses an outdoor  entertainment area that includes a Bar grill, sink, refrigerator, plenty of storage, and  deck  space that holds the tender while underway.

– Davit Aritex (1600lbs)

– Walker Bay Venture  14 Dinghy with YRM custom cradle

– Custom bar with sink and  refrigerator

– BBQ Grill

– LED lights above

Electronics

Pilot House – Lower Helm

Two 22″ Garmin Touchscreen Displays

Garmin 12 KW, 6-foot array  radar  available at any screen

Autopilot Simrad AP 48

Two Garmin 7″ Data  Displays GNX120  (depth, speed, wind)

Garmin VHF 315

Garmin Sounder Module GSD 26

Garmin Marine WiFi adapter kit

Garmin GSD-24  Digital Black Box Sounder

Satellite Weather Module

Garmin AIS-800

KVH Tracvision  HD7 SAT TV

Access to Garmin Marine Cameras (3)



FlyBridge – Upper  Helm

Two 22″ Garmin Touchscreen Multifunction Displays

Garmin 12 KW, 6-foot array  radar  available at any screen

Autopilot Simrad AP 48

Four Garmin 7″ Data  Displays

GNX120  (depth, speed, wind)

Garmin VHF 315

Garmin Sounder Module GSD 26

Garmin Marine WiFi adapter kit

Garmin GSD-24  Digital Black Box Sounder

Satellite Weather Module

Garmin AIS-800

Access to two engine room cameras and  FB aft camera

Master Stateroom

The master stateroom is full beam and  provides warmth  and  comfort. The king size  bed  is centerline with abundant drawer  storage and  hanging lockers to either side  of the bed.   To starboard there  is a beautiful Bow Front Cherry Dresser and  to port you find a comfortable bench/seating area with built in storage.  Additional storage is located in drawers beneath the bed  and  in the deck  below.  Shoji screens to port and  starboard permit light to enter  the stateroom while providing privacy in marinas. Aft of the master stateroom “Magic” has a large master head His and Hers heads with lots of countertop space, top of the line Vaccuflush heads, and  an oversize central shower that can be accessed from either head.

Cedar lined hanging lockers with automatic lights

High Gloss Teak  and  Holly Floors

King Size Bed with nightstands and  power  outlets

Oversize Shower with Grohe  fixtures

Grohe  chrome faucet at sinks

Large  Mirrors in Head Electric Vaccuflush Heads Large  LED TV

Granite countertops

VIP Stateroom

The VIP is spacious and  welcoming for your guests. A large Queen Size bed  sits centerline with drawer  storage underneath. Hanging lockers are  found to either side  of the bed  and  convenient overhead storage cabinets are located to port and  starboard above the bed.   There  are  2 large overhead hatches with block out shades and screens.  These overhead hatches are  large enough to act as an escape hatch  as well.  These open  and  provide natural light and  ventilation in nice weather.  This room has private access to its own VIP head. This head has a separate stall shower and  oversize opening portlight

Queen Size bed

2 large overhead hatches

2 large cedar lined hanging lockers

Storage Drawers under bed

Overhead storage cabinets

Vaccuflush head

LED TV

Satin Cherry  Cabinetry

Teak and  Holly Floors

Granite countertop in Head

Port Guest Stateroom

This stateroom provides two single berths, hanging locker, and  drawer  storage. Large  portholes allow natural light to brighten the room. The en-suite guest head has plenty of storage for toiletries and  a large walk-in shower.  This model Marlow Explorer is sometimes built as a 4 stateroom boat  but when  the 3 stateroom version  is chosen this room is built larger making  it a really nice stateroom that is very comfortable for adults.

Twin Berths – large for adults

2 large opening Portlights in Stateroom and  one  in the head

Electric push  button  Vaccuflush head

Samsung 22” LED TV

Satin Cherry  cabinetry

Teak  and  Holly Floors

Crew Quarters

The crew quarters have  a separate private entrance from the rest  of the sleeping areas so those using  this space can  come  and  go without disturbing the family in the Salon. This space is configured with a Queen-sized single berth on the port side  and  an L shaped settee with a table to starboard.  The settee was built long enough to serve as an additional berth  when  you want to sleep one  more.   There  is a head with shower for the crew. This space also features a refrigerator, TV, and  ample storage for personal gear
Queen Bed

Seating area with table long enough to be a bunk

TV and  Stereo

Head  with separate shower

Separate AC control

Safety Equipment

6 Person Life Raft  (Offshore Commander 2.0)

EPIRB GlobalFIX V4

Personal Location Beacon PLB-425

FireBoy Automatic Fire Suppression System in the Engine Room  with Manual Override

Emergency Fuel Shut  Off Valves
