Specifications
Builder: Yontech Shipyard, Istanbul, Turkey
Year: 2018
Type: Cruising Sloop Yacht
Naval Architect: Taka Yat (Osman Tanju Kalaycıoglu)
Exterior Stylist: Osman Tanju Kalaycıoglu
Interior Designer: Örs Design
Construction: Strip plank + cold-molded Acajou epoxy hull, carbon composite hardtop, teak decks
Classification: RINA C+HULL@ MACH Y UNRESTRICTED NAVIGATION
Length Overall (LOA): 26.00 m
Length Waterline (LWL): 24.00 m
Beam: 6.20 m
Draft: 3.20 m
Gross Tonnage: 71
Displacement (full): 70 t
Ballast: 16 t
Cruising Speed: 8 knots (at 1,200 rpm)
Max Speed: 11.5 knots
Range: 800 nm
Fuel Capacity: 1,900 litres
Fuel Day Tank: 70 litres
Fresh Water: 2,000 litres
Grey Water: 1,400 litres (2×700)
Black Water: 700 litres
Rig & Sail Area
Air Draft: 33 m
Main Sail (Full-Batten): 167 m²
Blade Jib (Self-Tracking): 145 m²
Staysail: 66 m²
A-3 (Optional): 400 m²
Mast & Boom: Aluminium (painted/deep V)
Standing Rigging: Nitronic rod (ABS)
Running Rigging: DYNEEMA
Furlers: Reckmann RF90-3 (Headsail & Staysail)
Rigging Hydraulics: BAMAR
Sheet Trimming: Hydraulic Cylinders
Machinery
Machinery
Main Engine: Cummins QSL9 – 330 HP @ 1800 rpm
Gearbox: ZF 360A (2.192:1)
Propulsion: Duplex stainless shaft, 4-bladed Brunton Varifold Ø750 mm
Fuel Consumption: ~17 L/h at 8 knots
Fuel Filters: Racor
Electrical & Auxiliary Systems
Generators:
1 x 6 kW Northern Lights (220V, 50Hz)
5 kW (220V 1PH, 50Hz)
Power Systems:
Shore Power: 380V / 220V 3PH 50Hz
DC System: 24V
Battery Banks: Service, Navigation, Starting (GEL, MASTERVOLT)
Solar Panels: 10 units on hardtop
Chargers: 2 x 100A
Inverters: 2 x AC MASTER 24/2500 (MASTERVOLT)
Ancillary equipment
Steering: Manual (Lewmar), autopilot
Rudder: Carbon-epoxy sandwich spade with Jefa bearings
Bow Thruster: Lewmar 20hp Side-Power SP240/300TC-24-48
Pumps:
2 x Electric fire/bilge (engine room + bow)
1 x Emergency fire pump
Boiler: 2 x 1.5kW, 75L
Watermaker: Aqua Whisper 1400-2 (220 L/h)
Fresh Water Pumps: 2 x Whale (24V DC + 220V AC)
Toilets: Tecma electric freshwater
Air Conditioning: Webasto (min 72,000 BTU)
Keel: ST42 steel fin with lead bulb
Deck Equipment
Windlass: Lewmar V6 (2500 kW)
Auto Anchor: AA560 Maxwell
Winches:
2 x Lewmar 88/3 HST
2 x Lewmar 77/3 HST
Ground Tackle:
100 kg ULTRA 316 SS plough anchor
12 mm SS Chain (165m)
Spare: Ultra 21kg + 5m chain + 150m rope
Windows: Tempered, laminated solar-reflecting
Stanchions: 316L SS with gateways
Swim Ladder: Custom mountable
Passerelle: Hydraulic
Deck Tables: 4x, up-down adjustable
Portlights: Lewmar SS opening (aft cabins)
Navigation equipment
Compasses: 2 x Garmin 6” magnetic
Autopilot: Garmin GNX 120 XL
Echo Sounder: Panoptix PS-51 (thru-hull)
Radar: Garmin GMR 24xHD
GPS: 2 x GPS 19x NMEA 2000
Chart Plotters: Garmin GPSMAP 7416 (2 x helm, 1 x salon)
Displays: 6 x MI 20 Marine
Wind Instruments: Garmin
AIS: 1 x TB CS
VHF: 4 total
Loud Hailer: GARMIN
Safety & security equipment
Life Rafts: 2 x 8-man (in fiberglass containers)
Firefighting:
1 x 15 kg FM-200 (engine room)
Portable extinguishers throughout
Seawater firefighting system
Alarms & Monitoring:
Central system (Concilium)
Substations in crew mess & captain’s cabin
Fire alarms, float switches
Domestic equipment
Galley:
Bosch commercial cooker (4 hobs)
Bosch oven
Bosch dishwasher
Icemaker
Refrigeration:
Bosch 50L (Galley)
Bosch 300L (Salon)
Freezer (Top loading, lazarette)
Laundry:
1 x Bosch Professional washer
1 x Bosch Professional dryer
