SPECIFICATIONS



LOA	30.40m (99’ 9’’)
Hull length	28.50m (93’ 6’’)
Length at water line (fully laden)	26.92m (86’ 11’’)
Maximum beam	7.48m (24’ 7’’)
Draft fully laden	2.00m (6’6’’)
Displacement (unladen)	147t
Displacement (fully laden)	170t



ACCOMMODATION

Cabins	6
Heads	6 + day head
Crew cabins	3
Crew heads	3
People on board	17



FLAG & CLASS

• Flag State Cayman Islands (port of registry George Town
• Classification: RINA



MACHINERY

Fuel System:

Total Capacity: 27,300 litres (7,332 US gallons) Tanks: 4 storage tanks (6,125 litres each) + daily tank (2,800 litres) Equipment: 380 VAC fuel transfer pump, manual fuel transfer pump, Alfa Laval MIB303 fuel purifier/separator, tender fuel pump

Fresh Water System:

Total Capacity: 7,200 liters (4,000 liters + 3,200 liters tanks) Equipment: 2x 380 VAC freshwater pumps, water maker Idromar MC5 (150-200 l/h), chlorine dosing system, 2x 100-litre immersion heaters

Generators:

Type: 2 x 55 kW Kohler 55EFOZD Running Hours: 9,560 each

Engines:

Type: 2 x 1,200 HP MTU 8V M93 2000 Running Hours: 5,920 each

Propulsion:

Type: Shaft line Steering gear

Speed:

Maximum: 16.5 knots Cruising: 11.0 knots

Range:

3,200 Nautical Miles at cruising speed

Hull:

Type: Displacement with bulb

Stabilisation System:

Fins (with stabilisation at rest) Model: ABT TRAC 370 Additional: 2x PTO on main engines + 15 kW 380 VAC pump for stabilisation at rest mode



FUEL & CONSUMPTION

Classification and class notation RINA C  Hull Mach Short Range Exterior design  Filippetti Yacht Fuel Consumption in navigation (main engines + 1 gen on 50-60% load)   @1100 rpm speed 8,5 – 9,0 kts – 40 l/h Fuel Consumption in navigation (main engines + 1 gen on 50-60% load)   @1350 rpm, speed 10,0 – 11,0 kts – 80 l/h Generator fuel consumption Between 6 l/h – 18 l/h depending on load Anchoring gear  2x Maxwell 4500 windlasses (380V), 2×150 m 14 mm chains with stud link Bow thruster ABT 55 kW with tunnel 24”, counterrotating screws



NAVIGATION & COMMUNICATION

Electronic Navigation Main Radar Furuno FAR15 Aux Radar Furuno Navnet2 + plotter, TIMEZERO ECS Autopilot Furuno, NAVTEX Furuno, SATCOM C Furuno Felcom, 2x VHF Furuno, BNWAS Furuno Monitoring system Furlanetto (monitoring tank levels, navigation/exterior lights, bilges, fire detectors, pumps functions, power management shore/generator, steering system)



MARINE SANITATION AND SAFETY SYSTEMS

Galley Grey Water Management:

Capacity: 1200 liters Dedicated galley grey water pump + common manifold Priming valve from freshwater system Vacuum metering instrument

Sewage Treatment System:

Model: Ecomar 8AC Holding Tank Capacity: 1 cubic meter

Bilge Water System:

Primary Pump: Gianneschi ACM, 380V AC (interchangeable with fire pump) Emergency Pump: Gianneschi Diesel fire/bilge pump with common manifold and priming valve Additional: 24V electric pump in each bilge well, high level alarms for ECR and wheelhouse Portable Diesel Fire/Bilge Pump Dedicated Bilge Tank: 1 cubic meter

General Grey Water Tank:

Capacity: 1500 liters Dedicated grey water pump + common manifold Priming valve from freshwater system Vacuum metering instrument

Black Water Tank:

Capacity: 2200 liters Dedicated black water pump + common manifold Priming valve from freshwater system Vacuum metering instrument



SOUND SYSTEM & ENTERTAINMENT

Main Sound System:

Brand: SEALUX Features: Connectable to loudspeakers in all areas Coverage: Includes main saloon, with separate zones for upper deck, sun deck, bow deck, and aft deck

Digital Entertainment:

Apple TV available for streaming and multimedia playback

SAFETY & SECURITY

Firefighting System:

Control Panel: CATEF fire control panel with detectors in all spaces and call points Fixed Systems: FM200 fixed firefighting system in Main Engine Room and a dedicated FM200 fixed tank in ECR (Electronic Control Room) Pump: Gianneschi ACM 380V AC fire pump (interchangeable with bilge pump) Fire Hoses: 4 total (2 on main deck, 1 on upper deck, 1 interior) Portable Equipment: Portable fire/bilge pump with connection to fire main Fire Extinguishers: Available in all zones



TENDERS & TOYS

Tender:

Type: BCT 380 VAC Features: Servo-assisted hydraulic steering with emergency pump and switchover valves Model: Williams 505 Diesel Engine: Yanmar 4JH-4HTBE, 81 kW Running Hours: 500 Drive: Jet drive Year: 2014

Jet Ski:

Model: Seadoo Spark Trixx Power: 66 kW Year: 2021

Seabob:

Model: Cayago Seabob Year: 2015

Water Sports Equipment:

2x Water skis 1x Wakeboard Assorted fins and snorkels
