Machinery

• Engine: 1 x John Deere JD 6135SFM85 485kW at 2100 rpm with ZF 360 2.917:1
• Engine hours: 503 hours
• Gear Box ZF360 2.917:1
• Stabilisers: No
• Propellers: Single feathering propeller
• Bow and Stern Thrusters: Yes

Generators & Auxiliary Systems

Generators:  1x 17.5 Onan MDKDR 17.5 Kw-12V / 1-230-50

Generator hours: 383 hours

Electrical system

• Power supply:
  •  AC Power – Shore connection and generator
  • DC Power – Service batteries
  • Emergency batteries
  • Stern Thruster batteries
  • Engine/generator start batteries

• DC Power:
  • Bosch Service batteries      150 Ah
    • 10 pcs  In engine room
  • Emergency batteries                     150 Ah
    • 2 pcs     In utility space
  • ME. Start Batteries    180 Ah
    • 2 pcs   In engine room
  • Generator start batteries     90 Ah
    • 1 pcs   In engine room
  • Stern Thruster batteries     180 Ah
    • 2 pcs   Under master cabin bed

There are two battery charger/inverters in for service batteries in the engine room (2x 24V 70 Amp/3000 VA)

Air conditioning: MarineCool unit in engine room with separately controllable units in all 6 cabins, galley and saloon.

Tank Capacities

Water Makers: Aquaprime

Grey/Black Water Capacity: 3200 L

• 2x Raymarine transducers in the engine room bilge

Fire and Bilge:

• Bilge and fire fighting systems are interconnected. Each of them has separate pumps and these pumps back up each other.
• There are 3 waterproof compartments on the boat. Aft, engine room, forward. Each of these compartments has a main bilge suction. (Engine room has got two suctions).
• These bilge suctions are connected to the main bilge collector in the engine room. By that to this collector, the bilge water in the intended compartment can be sucked with the bilge pump.

Ancillary Equipment

• Sail model ONESAILS (Italian make)
• Sail measurements
• Mainsail – Hydranet (Dyneema) Triradial; LUFF 32m LEECH 34m FOOT 12m AREA 250m2
• Genoa – Dacron Crosscut; LUFF 36 LEECH 32.5 FOOT 15.5 AREA 252m2
• The Mast and Boom spars are aluminium
• Staysail – LUFF 25.5m LEECH 23.5m FOOT 7.5m AREA 82m2

Safety & Fire Protection

• Lifesaving:             Life raft for 10 people
• Fire Fighting:         Full fire and smoke detection system with automatic foam fire

                               extinguishing system in the engine room (controllable from outside the                                 engine room).

                               Fire distinguishers in every cabin.

Communication Equipment

• Radio: Raymarine
• VHF:   Raymarine

Navigation Equipment

• Raymarine chart plotter (Axiom) – Master (secondary on Bridge)
• Alarm monitoring system display
• Raymarine Multifunction display
• Delta control panel (large VDU top right)
• Generator control panel
• Main hydraulic system control panel
• Bow thruster control panel
• Main engine control panel
• Steering gear control unit/joystick
• Electronic throttle
• Windlass control button
• Port anchor, Starboard anchor, horn control button, bow deck lights, spreader lights, instrument lights.

Deck Equipment

• 2x  Passerelles at the stern of the yacht:            1x shore to the upper deck

                                                                                    1x to lower stern platform

• Swimming platform at the stern which can lower into the water.
• Cockpit retractable sunshade.
• Pushpit mounted BBQ

Audio & Visual Equipment

• Crew mess – TV with various plug-in options
• Option to add VHF antenna on the mast to place satellite tv
• Stereo speakers in the salon

Galley & Domestic Equipment

Siemens:          1x Large fridge

                         1x Freezer (there is also a second fridge in the cockpit).

                         1x Oven

                         1x Hob

                         1x Microwave (runs on service batteries therefore there is no need for shore                                  power or generator)

Tenders & Watersport Equipment

• 4 Seater Suzuki engine tender
• 2x paddle boards
• Waterskis
• 1x diving set for hull inspection on water

Accommodations

Cabin layout:

1 x Full beam Owners Suite with ensuite bathroom

2 x Double VIP cabins each with ensuite bathroom

1 x Twin cabin with ensuite bathroom

Refit 2025

Jasmina III 2025 dry dock winter works and cruising plans for the season

Dry Dock work completed:

1. Bow thruster and Stern thruster propellers removed, cleaned and replaced.
2. Folding prop removed to workshop for full maintenance including re-greasing.
3. Cockpit fridge sealant renewed.
4. All deck cushion covers removed and laundered.
5. All S/S parts on deck washed and polished.
6. Anchor plates sanded and polished.
7. Windlass maintenance carried out.
8. Watermaker winterized in October 2024 ready for de-winterizing in May 2025.
9. Mainsail removed to loft, washed, luff wear damage repaired, re-installed.
10. Hull below water fully cleaned, sanded, primed and double coat of antifouling applied.
11. All sea cocks and sea water intake filters cleaned and maintained.
12. All anodes replaced with new.
13. Topsides of hull – sanded, primed, touch up painted and polished.
14. Tender outboard annual maintenance done.
15. Main engine and generator annual maintenance done.
16. Biennial chemical treatment and cleaning of air conditioner and all fan coil units done.
